Code CR5000 User Manual

USER MANUALNORTH AMERICAMANUAL VERSION 02RELEASE DATE: APRIL 2015CR5000Configuration Guidewww.codecorp.com YouTube.com/codecorporation®

10D021992_02 CR5000 User Manual16.0 - Reader PinoutsThe connector on the CR5000 is an RJ-50 (10P-10C). The pinouts are as follows:Pin 1 +VIN (5v) Pin

11D021992_02 CR5000 User Manual18.0 - Warranty*The CR5000 carries a standard three year limited warranty as described herein. Cables have a 30 day war

2D021992_02 CR5000 User ManualStatement of Agency ComplianceCode Reader™ 5000 User ManualThe Code Reader™ 5000 (CR5000) has been tested for compliance

3D021992_02 CR5000 User ManualTable of Contents1.0 - Included Items ...

4D021992_02 CR5000 User Manual 1.0 - Included Items (if Ordered) CR5000 (Model #: CR5020 or CR5025)USB 2.0 Cable RS232 Cable 5VDC Power Supply

5D021992_02 CR5000 User Manual2.0 - Attaching and Detaching a Cable 3.0 - Set Up2x10 Sec.1Plug InWait 10 SecondsLED will FlashReader will Beep1234

6D021992_02 CR5000 User Manual6.0 - Reading Ranges4.0 - Using a CR5000 in Presentation Mode5.0 - Using a CR5000 in Handheld ModeNote: Handheld work

7D021992_02 CR5000 User Manual7.0 - Reader FeedbackScenario Top LED Light SoundCR5000 Successfully Powers Up 1xCR5000 Successfully Enumerates with Hos

8D021992_02 CR5000 User Manual11.0 - CR5000AVThe CR5000AV (Model# CR5025) is stand-alone age verication solution that does not require a PC or manual

9D021992_02 CR5000 User Manual13.0 - CR5000 Overall Dimensions3.55"(90.30 mm)2.80"(71.23 mm)5.95"(151.14 mm)14.0 - USB Cable Example wi
